Euromix® SM
Supermobile concrete plants EUROMIX® SM remove limits in savings of time and cost. The installation is performed in just one eight-hour shift. The embodiments are optimized for different capacity requirements – from 80 to 170 m³ per hour, but also allow modular expansion. The assembly is designed for all year round operation irrespective of weather conditions.
Fakts
- ready-for-operation transport units
- assembly time per 480 minutes without the need of building foundations
- fully galvanized structure
- microprocessor control according to EN206
- high-performance twin-shaft mixer
- modularly expandable
TECHNICAL DATA
| EUROMIX SM | 1600 | 2200 | 2500 | 3000 | 3300 | 4000 |
|---|---|---|---|---|---|---|
| Output capacity (m³/h) | 80 | 100 | 115 | 130 | 145 | 170 |
| Mixer output (m³) | 1.67 | 2.25 | 2.50 | 3.00 | 3.33 | 4.00 |
| Aggregate weigher (kg) | 3 500 | 5 000 | 6 000 | 7 500 | 8 000 | 10 000 |
| Cement weigher (kg) | 750 | 1 200 | 1 800 | 2 100 | 2 100 | 2 400 |
| Additive weigher (l) | 2×12.5 | 2×12.5 | 2×12.5 | 2×25 | 2×25 | 2×25 |
| Water weigher (l) | 350 | 530 | 600 | 720 | 800 | 1 000 |
